Basit boru düzeni nedeniyle, radyatörün temizlenmesi çok kolaydır.
Zaman ötesi karakteriyle evrensel bir tasarım.

Model özeti

These high quality design radiators are made in Austria. The design radiators manufactured by VOGEL&NOOT meet numerous internationally recognised quality standards and the manufacturing processes at all of the production sites have been ISO certified

CAVALLY-VM overview



 Width Uzunluk 498, 596, 742, 887
 Height Yükseklik 796 1196 1756

 Connections Connections: 2 x external thread G 3/4 (for valve connection set), 2 x internal thread G 1/2, and 1 x internal thread G 1/4 (for vent plug)

Test positive pressure  Test aşırı basıncı: 13 bar

Maximal positive operating pressure  Maks. pozitif çalışma basıncı: 10 bar

Maximal operating temperature  Maks. çalışma sıcaklığı: 110 °C

Teknik bilgiler

Get an overview of the most important technical data. For further information, please download the featured pdf files.

Bağlantı modları

CAVALLY-VM connection examples CAVALLY-VM connection examples

flow Flow

Return Return

Vent plug Vent plug

Electric connection Electric connection

Boss spacing Boss spacing

Connections Connections: 2 x external thread G 3/4 (for valve connection set),
2 x internal thread G 1/2, and 1 x internal thread G 1/4 (for vent plug)

Test positive pressure Test overpressure: 13 bar

Maximal positive operating pressure Max. positive operating pressure: 10 bar

Maximal operating temperature Max. operating temperature: 110 °C

Accessory: PTC electric heating element
CAVALLY-VM radiators fi tted with an electric heating element can also be used at times when the regular heating system is switched off. It is absolutely necessary to take account of the power-ratings assigned to the electric heating elements.

Basic standard accessories (included):
• a pivotable vent plug, G 1/4, and two dummy plugs,
G 1/2, nickel-plated brass, self-sealing, factory-sealed
• a valve connection set with angled two-pipe design
• covering rosette in matching radiator colour
• wall fastening set matching the radiator colour
• fitting aid
• instruction sheet

Ebatlar [mm]

CAVALLY-VM dimensions CAVALLY-VM dimensions
